Portable 4kw Residential Steam Generator

China Portable 4kw Residential Steam Generator supplier

Large Image :  Portable 4kw Residential Steam Generator

Product Details:

Place of Origin: China
Brand Name: KSA
Certification: CE
Model Number: KSA-E40

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: 1 set/carton
Delivery Time: 1-3 workdays
Payment Terms: T/T, Paypal, Western Union,
Supply Ability: 1800 sets
Detailed Product Description
Power: 4.0kw Voltage: 110V/220V/400V
Material: Stainless Steel Phase: Single
Power Source: Electric Type: Wet Steam Sauna
Usage: Steam Sauna Room Shape: Cuboid
Color: Grey

KSA-E40 steam generators 4.0kw/220v-230v for steam room with auto-descaling



Quick Detail:



  1. Type: Wet Steam Sauna
  2. control panel: digital and optional
  3. Power output: 4.0kw
  4. Voltage: 110V/220V/400V
  5. Current: 18.2A
  6. Main Material: stainless steel tank, galvanizing and powder coated shell
  7. Color: grey
  8. phase: single
  9. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  10. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  11. Shape: Cuboid
  12. Size: 425x160x300mm
  13. Room volume(cubic meter): 3~5
  14. Usage: steam sauna room
  15. working time: 1~60 minutes or long time
  16. Heating: heat elements
  17. Power source: Electric
  18. Time Setting: 1-60mins
  19. Temperature range to control: 95 F degree~131 F degree
  20. Temperature range to show on control panel: 43 F degree ~140 F degree





We are the manufacturer for steam bath products.

  • Electric Heater Type: hot steam
  • Heating Element: heat element
  • Installation: Freestanding, Wall Mounted
  • Certification: CE, RoHS
  • Function: Adjustable Thermostat,Overheat Protection,Remote Controlled
  • Use: Bathroom/steam bath
  • Place of Origin: China (Mainland)
  • Brand Name: KSA
  • Model Number: KSA-E40
  • Power: 4.0kw
  • voltage: 230v/400v
  • phase: 1/3
  • suit for steam room: 3-5CBM
  • unique function: Auto descaling
  • heat element: SUS304
  • shell colour: greyish-green





Automatic electric steam generator portable 4kw for shower



Description:



Model:KSA-E30,KSA-E40,KSA-E45,KSA-E50. KSA-E60,KSA-E70,KSA-E80. KSA-E90,KSA-E105,KSA-E120,KSA-E150. KSA-E180. KSA-E225. KSA-E240

The Standard steam generator is the second generation of our products which covers all power sizes from 4KW to 24KW, 220~240V AC or 380~415V AC. When equiped with KSA-200 digital control panel, the temperature, working time  and even steam room light could be controlled digitally. You could switch between temperature units, and also "Pause" the steam generator from heating  when needed without shutting off the whole system. Optional reomote controller could also be selected to let you control the steam generator from distance.

 The Standard steam generator features auto water supplementary system, over-pressure and over-heat protection, and In-generator auto drain system.  The segment-heating and self-diagnose function make the heater energy-efficient and easy-operation.

Mineral buildup is the main problem affecting steam generator performance and life of heating elements. Non-resolvable particles in water could be removed by adding filter to the water inlet of steam generator, but resolved scale minerals dissolve under high temperature, and then precipitate layers of rocklike deposits inside water tank and on surface of heating elements when water cools down. As a result of water scale build up, it may clog pipes, affecting heat dissipation of elements and eventually damage them. Thus washing and cleaning the steam generator after use is extremely important for hard water area or heavy-duty commercial use. With auto drain system, the inner tank is washed and drained thoroughly by an 8kg powerful pump to eliminate mineral build up, which could significantly extend the life of heating elements and the steam generator as well.

Qualified for CE certification of Europe Union and Tests of China Import and Export Commodity Inspection.

The delicately designed Standard series steam generator is durable and efficient, so it covers most requirements of customers, and selected as the "Best-seller" product. We would recommend it as our "STAR" product to everyone.





Applications:



For 3~5 m³ residential and commercial steam baths/bathroom use





Specifications:



  1. Control panel with Digital display
  2. Control panel used the advanced inducing technology
  3. Controls sauna temperature 35 degree to 55 degrees
  4. Controls sauna time 1 minute to 60 minutes or long time
  5. Intelligent to heat by segment
  6. Intelligent to fill water with steam
  7. Intelligent to do a self flushing cycle
  8. Light can be connected to controller
  9. Intelligent to indicate fault with the code
  10. Can pause at working
  11. To show CH can working for long
  12. Intelligent to save two sets of temperature, can individual set time by memory
  13. Automatically shuts down when water level is too low
  14. Temperature high limit switch
  15. Waterproof grade: IPX5
  16. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  17. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  18. We will provide some spare parts to our customer as replacement.





Parameters:

Model

Power KW

Room volume (m³)

Power requirements           50/60Hz

Current (A)

Power        wire (Copper)          N*mm2

Dimensions  CM

Packing dimensions CM

Gross weight kg

KSA-E40

4.0

3~5

220-240V~

18.2

3*2.5

42.5*16*30

54.5*21.5*42

10.5~11





Competitive Advantage:



  1. Intelligent to heat by segment, fill water with steam, automatic to turn off and wash with pressure to drain.
  2. Light can be connected to illumine, water inflow to magnetize and filtrate etc.
  3. Intelligent to indicate fault
  4. To show CH can working for long
  5. Can pause at working
  6. Intelligent to save two sets of temperature, can individual set time by memory
