Energy Efficient Electric Sauna Stoves sus304 12.5kw / 400V with 3 phase

Energy Efficient Electric Sauna Stoves sus304 12.5kw / 400V with 3 phase

Quick Detail:

• Shell material: sus304
• Electric heater type: electrical heater
• Heating element: heat element
• Installation: Freestanding
• Use: sauna room
• Brand name:KSA
• Model: KSA-H125
• Power: 12.5kw
• Suit for sauna room volume: 10~18 m³
• Voltage: 400v/3 phase
• Stone volume: ~30kg
• 1-8 hour pre-selected time setting and 1-4 hour working time under A model
• Maximum 12 hours working time under B model
• Controller:  digital controller


Energy efficient Electric Sauna Heater sus304 12.5kw / 400V with 3 phase

Description:

• We use low voltage controller and separate electrical box bring reliable safety
• Large and improved time display screen showing time in hours
• Extra switch for sauna room lamp
• High temperature cut-off for both sauna room and sauna heater. Double safety protection
• stainless steel shell  .
• Large and improved time display screen showing temperature in Centigrade or Fahrenheit according to the customer's preference
• The temperature can adjusted from 50-110 centigrade or 122-230 Fahrenheit Sauna heater will Sequential heating according the detected sauna room temperature and the setting temperature. It save energy and prolong the main parts' life.
• Customer can preset the working time and the waiting time in A and B model. Under A model, user can set waiting time from 0 to 8 hours. When the time count down to zero, it will switch to B model automatically and works as the setting under B model
• Under B model, user can set working time from 30 minutes to 12 hours or no time limited.

Applications:

For dry type sauna room in hotel and chamber commercial use

Specifications:

1. Type:For Traditional Sauna
2. Control panel: Built-in control /Out control
3. Power output: 12.5kw
4. voltage: 380V~400V
5. phase: three
6. Current: 18A
7. Main Material: stainless steel shell with industrial grade Teflon coated heating elements
8. Color: stainless steel color
9. Features: high-temp protection device, anti-corrosive and heat-proof
10. Auto function: auto power off
11. Shape: Cuboid
12. Size: 650x490x440(560 bottom)mm
13. Room volume(cubic meter):10~18
14. Stone volume(kg): ~30
15. Usage: sauna room
16. working time: 30~720 minutes
17. Heating: heat elements
18. Power source: Electric
19. Time Setting: 30~720 minutes
20. Temperature range to control: 40-105 ℃(104-221 ℉)
21. Waiting time :0~8 hours
22. Working time : maximum 12 hours

Technical data:

Competitive Advantage:

1. double safety protection system sauna heater
2.low voltage controller +electrical box,
3.CE standard, interlock function
