12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat Protection

China 12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat Protection supplier

Large Image :  12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat Protection

Product Details:

Place of Origin: China
Brand Name: KSA
Certification: CE
Model Number: KSA-E120

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: 1 set/carton
Delivery Time: 1-7 workdays
Payment Terms: T/T, Paypal, Western Union,
Supply Ability: 1800 sets
Detailed Product Description



12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat Protection





Quick Detail:



  1. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  2. Power output: 12.0kw
  3. phase: three
  4. voltage:380V
  5. Current: 18.2A
  6. Temperature range to control: 95 F degree~131 F degree
  7. Temperature range to show on control panel: 43 F degree ~140 F degree
  8. Type: Wet Steam Sauna
  9. control panel: Black/ white touch screen computer control panel
  10. Main Material: stainless steel water tank and shell
  11. Color: stainless steel
  12. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  13. Shape: Cuboid
  14. Size: 47.5*18.5*45cm
  15. Room volume(cubic meter):11~14
  16. Usage: steam sauna room
  17. working time: 1~60 minutes or long time
  18. Heating: stainless steel heat elements
  19. Power source: Electric
  20. Time Setting: 1-60mins





Competitive Advantage:



Every KSA-E steam generator is subjected to 6 strictly controlled tests:
    1. 48 hour continual test for circuit board
    2. Controller is tested for all functions
    3. High voltage test
    4. Earthing resistance test
    5. Power test.
    6. Operational test of every steam generator before packing





KSA-E steam generator have middle size to install easily. They have 304 stainless steel water tank, 304 stainless steel heating element with high quality Teflon to prevent water scale.



What’s the steam bath?

A steambath is an ancient type of bath, first made popular by the ancient Greeks and Romans. The origins of the steam bath come from the Roman bath, which began during the height of the Roman Empire. Ancient Roman baths served many community and social functions within Roman society. Everyone in Rome used Roman public baths, regardless of socioeconomic status.





12kw Stainless steel steam generator , 380V electric wet steam generator for steam room



Description:





12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat ProtectionControls


• Water-tight control mountable in/out of steam room/touch screen type
• Electronic 1~60-min. and On/Off control with indicator light.
• Electronic digital Advanced Designer series.
• 24-hour clock timer with preset on & off operation.
• Multi-memory temperature & time function offers individual settings.
• New Design stainless steel steam head .
• Fragrance of your choice
• Chromatherapy RGB.
• LED light controlled on the touch screen controller
• Hi-powered waterproof marine speakers(optional).





12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat ProtectionDurability



• Type 304 high-quality stainless steel boiler tank & shell.
• Or Galvanized enclosure with superior powder coating, corrosion-resistant, excellent clour and gloss retention.
• Industrial process high-quality 304 stainless steel heating elements with Teflon, corrosion-resistant.
• Easy Maintenance electrical probe for water level control

• Water inlet valve enhanced for 10 million operations.
• Well insulated steam boiler improves energy efficiency and safe operation.





12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat ProtectionInstallation



• All compression-fitting connection.
• Sediment strainer factory-installed.
• Steam unit and water sensor both come with easily accessible repair entrance.
• Motorized drain valve with the option for manual flush as needed.





12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat ProtectionOperation



• Compact, easy to install.
• Energy-efficient, inexpensive to operate.
• Super-quiet operation, continuous smooth steam.
• Completely controlled by programmable microprocessor.
• Electronic thermostat and sensor for accurate steam room temperature.
• Standby Mode preheats the unit, steam is ready on-demand.
• Built-in 60 min safety shutoff.
• Automatic flush system removes sediments, prevents calcium buildup, and is programmed to refill fresh water for next steam bath, making it hygienic.
• Exclusive drain-cooling system cools the hot water before flushing, meets building codes, and is safe for the user.





12.0kw Bathroom Fast Response Sauna Steam Generator , Electric Wet Steam Generator With Over Heat ProtectionQuality Assurance


• ISO 9001:2008 Quality Management System ensures advanced design, perfect pre- & post-production quality and superior customer service.
• 2-year limited warranty or optional lifetime warranty offers you a worry-free lifestyle.
• Specified by leading architects, consultants, designers throughout worldwide.
• Successfully served in prestigious projects all over the world.





with new 2014 touch screen controller !





Applications:



For 11~14m³ residential and commercial steam baths



A daily steam bath is a remarkable way to indulge yourself. It causes the perspiration that is the single healthiest thing you can do for your skin. Stress and negativity quickly dissipate in the soft clouds of intense yet comforting heat. A few minutes of steam daily, in the comfort of your own home, is an opportunity to improve your overall well-being in every way.





Specifications:



Host of Features:



  1. Touch screen computer control panel with digital display Can pause at working
  2. To show CH can working for long
  3. Intelligent to save two sets of temperature, can individual set time by memory
  4. Automatically shuts down when water level is too low
  5. Temperature high limit switch
  6. Control panel used the advanced inducing technology
  7. Controls sauna temperature 35 degree to 55 degrees
  8. Controls sauna time 1 minute to 60 minutes or long time
  9. Intelligent to heat by segment
  10. Intelligent to fill water with steam
  11. Intelligent to do a self flushing cycle
  12. Light can be connected to controller
  13. Intelligent to indicate fault with the code
  14. Waterproof grade: IPX5
  15. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  16. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  17. We will provide some spare parts to our customer as replacement.





Parameters:



Model

Power KW

Room volume (m³)

Power requirements           50/60Hz

Current

(A)

Power        wire (Copper)          N*mm2

Dimensions  CM

Packing dimensions CM

Gross weight kg

KSA-E30

3.0

2~4

220-240V~

13.6

3*2.5

42.5*16*30

54.5*21.5*42

10.5~11

KSA-E40

4.0

3~5

220-240V~

18.2

3*2.5

KSA-E45

4.5

3.5~5.5

220-240V~

20.5

3*2.5

380-415V3N~

6.8

5*1.5

KSA-E50

5.0

4~6

220-240V~

22.7

3*2.5

380-415V3N~

9.1

5*1.5

KSA-E60

6.0

5~7

220-240V~

27.3

3*4.0

380-415V3N~

9.1

5*1.5

KSA-E70

7.0

5.5~8.5

220-240V~

31.8

3*6.0

47.5*18.5*45

53.5*23*59

15.6~16.2

380-415V3N~

11.4

5*2.5

KSA-E80

8.0

7~10

220-240V~

36.4

3*6.0

380-415V3N~

13.6

5*2.5

KSA-E90

9.0

8~11

380-415V3N~

13.6

5*2.5

16.4~17

KSA-E105

10.5

9~12

380-415V3N~

15.9

5*2.5

KSA-E120

12.0

11~14

380-415V3N~

18.2

5*2.5

KSA-E150

15.0

13~18

380-415V3N~

22.7

5*2.5

51*18.5*46

56.5*23*59

17.5~18.5

KSA-E180

18.0

16~22

380-415V3N~

27.3

5*4.0

KSA-E225

22.5

21~28

380-415V3N~

34.1

5*6.0

KSA-E240

24.0

22~30

380-415V3N~

36.4

5*6.0

Notice: KSA-E steam generator are equiped with auto drain system. 9~12 KW units could be customized to 220~240V on request.







KSA-E30 KSA-E40 KSA-E45 KSA-E50 KSA-E60



KSA-E70 KSA-E80 KSA-E90 KSA-E105 KSA-E120





KSA-E150 KSA-E180 KSA-E225 KSA-E240
