50hz - 60hz Vapor Steam Bath Generators Auto Power Off Improve Circulation

China 50hz - 60hz Vapor Steam Bath Generators Auto Power Off Improve Circulation supplier

Large Image :  50hz - 60hz Vapor Steam Bath Generators Auto Power Off Improve Circulation

Product Details:

Place of Origin: China
Brand Name: TOLO
Certification: CE
Model Number: TOLO-E225

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: 71.5*44.5*60.5cm /1 set/carton
Delivery Time: 1~2days
Payment Terms: T/T, Paypal, Western Union,
Supply Ability: 2000sets/month
Detailed Product Description

50hz - 60hz Vapor Steam Bath Generators Auto Power Off Improve Circulation









Quick Detail:



Type:

Steam sauna

Place of Origin:

Guangdong China (Mainland)

Brand Name:

TOLO

Model Number:

TOLO-E225

Function:

Wet Steam

Feature:

waterproof touch screen control panel

Capacity:

19~26

Main Material:

stainless steel , metal,copper

Power:

22.5kw

voltage:

110v/230v/400v

phase:

single/three

temperature

adjustment range:

30-60 centigrade

working time:

15-240 minutes or long time

parts:

controller/nozzle/connection wire/pressure valve/temperature sensor

warranty:

1 year





Description:



1. The TOLO-E waterproof touch screen controller has 6 bottoms to set working stages.

2. The waterproof touch screen control panel with a digital display to enable temperatures of 30 to 60 degrees centigrade and time duration 1 to 60 minutes or continual operation with touch keys for a steam room light, keyboard lock, manual drain down etc.

3. The drain system of the TOLO-E stainless steel generator is independent research and development by our engineer. Its features big water flow. No situation that water scale plugs up the water outlet.

4. Safety features include boil dry protection, thermal overload safety cut out and pressure relief valve.

5. Each generator has 3 groups of heating elements to provide sequential heating (from cold all 3 groups operate for maximum power and rapid heating, when the steam room temperature is almost reached, then group 1 stop, when the required temperature is achieved, then group 2 stop.

6. The group 3 alternates on and off to gently maintain the temperature without large fluctuations improving user comfort).

7. TOLO-E steam generators have an auto drain down with a self flushing cycle to dump the boiler contents in a controlled manner - at the end of each steaming session the drain valve will open and after a short time the cold water inlet valve will open to give a period of continuous flushing and draining.Flushing and draining the boiler reduces the build up of damaging limescale, cooling the elements before the final drainage helps prolong their useful life.

8. They have 304 stainless steel water tank, 304 stainless steel heating element with high quality Teflon to prevent water scale.

9. TOLO-E steam generator have middle size to install easily

10. working time 1-60mins can be adjusted or long ,the setting temperature of the steam will be in 6-60C degrees and can be adjusted between 35-55C degree (95-131F degree).

11. TOLO-E steam generators feature an advanced electronic control with on board diagnostics having a series of LEDs to show each operation of the gernerator.





Applications:



For 19~26m³ residential and commercial steam baths

Used in wellness center, bakery(fermentation),hotel,hospitals, nursing homes, rehabilitation centers





Specifications:



The Parameters of TOLO-E steam generator :



Model

Power  (kW)

Heating elements

(N*kW)

Voltage/Current      (V/A)

Power wire

(N*mm2)

Breaker

(A)

Room volume

(m3)

Dimension

(L*W*H)  (mm)

TOLO-E30

3.0

2*1.5

220-240/13.6

3*2.5

16

2~3

425*160*315

TOLO-E40

4.0

2*2.0

220-240/18.2

3*2.5

25

3~5

TOLO-E45

4.5

3*1.5

220-240/20.5

3*2.5

25

3.5~5.5

380-415/6.8

5*1.5

16

TOLO-E50

5.0

2*1.5+1*2.0

220-240/22.7

3*2.5

32

4~6

380-415/9.1

5*1.5

16

TOLO-E60

6.0

3*2.0

220-240/27.3

3*4.0

40

5~7

380-415/9.1

5*1.5

16

TOLO-E70

7.0

2*2.5+1*2.0

220-240/31.8

3*6.0

40

5.5~8

475*185*450

380-415/11.4

5*2.5

16

TOLO-E80

8.0

2*2.5+1*3.0

220-240/36.4

3*6.0

60

6.5~9

380-415/13.6

5*2.5

16

TOLO-E90

9.0

6*1.5

380-415/13.6

5*2.5

16

8~11

TOLO-E105

10.5

3*1.5+3*2.0

380-415/15.9

5*2.5

25

9~12

TOLO-E120

12.0

6*2.0

380-415/18.2

5*2.5

25

11~14

TOLO-E150

15.0

6*1.5+3*2.0

380-415/22.7

5*2.5

32

13~18

510*185*460

TOLO-E180

18.0

9*2.0

380-415/27.3

5*4.0

40

16~22

TOLO-E225

22.5

9*2.5

380-415/34.1

5*6.0

60

19~26

TOLO-E240

24.0

6*2.5+3*3.0

380-415/36.4

5*6.0

60

22~30





The origin of the sauna



A steambath is an ancient type of bath, first made popular by the ancient Greeks and Romans. The origins of the steam bath come from the Roman bath, which began during the height of the Roman Empire. Ancient Roman baths served many community and social functions within Roman society. Everyone in Rome used Roman public baths, regardless of socioeconomic status. TOLO wants to make this life-style go on.





The benefit of steam sauna:



A daily steam bath is a remarkable way to indulge yourself. It causes the perspiration that is the single healthiest thing you can do for your skin. Stress and negativity quickly dissipate in the soft clouds of intense yet comforting heat. A few minutes of steam daily, in the comfort of your own home, is an opportunity to improve your overall well-being in every way.







Machine Size: TOLO-E30 TOLO-E40 TOLO-E45 TOLO-E50 TOLO-E60

Machine Size : TOLO-E70 TOLO-E80 TOLO-E90 TOLO-E105 TOLO-E120

Machine Size: TOLO-E150 TOLO-E180 TOLO-E225 TOLO-E240





Competitive Advantage: CE certificate!



Every TOLO-E steam generator is subjected to 6 strictly controlled tests:
    1. 48 hour continual test for circuit board
    2. Controller is tested for all functions
    3. High voltage test
    4. Earthing resistance test
    5. Power test.
    6. Operational test of every steam generator before packing
