Single Phase Sauna Steam Generator 110V Automatic For Heat Recovery

Single Phase Sauna Steam Generator 110V Automatic For Heat Recovery

Sauna Steam Generator Quick Detail:

1. control way: wired touch screen control panel
2. Power output: 5.0kw
3. Voltage: 110V/220V/380~415V
4. Time Setting: 1-60mins
5. Temperature range to control: 95 F degree~131 F degree
6. Temperature range to show on control panel: 43 F degree ~140 F degree
7. Main Material: stainless steel tank and shell
8. Color: mirror finished stainless steel color
9. phase: 1/3
10. Current: 22.7A/9.1A
11. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
12. Auto function: auto water inlet , auto drain, auto flushing, auto power off
13. Shape: Cuboid
14. Size: 425x160x300mm
15. Room volume(cubic meter): 4~6
16. Usage: steam bath room
17. working time: 1~60 minutes or long time
18. Heating: heat elements
19. Power source: Electric

Description:

We have more than 10 years manufacturing experience for sauna equipment.

TOLO steam generator main feature :

                  A. steam out right long when cold water fill in

                  B. Auto turn off when reaches working time.

                  C. Auto drain after power off

                  D. self flushing heating element

                  E. Intelligent to indicate fault with code

                  F. Protect when overheating

                 G. Auto power off when shortage of water

                 H. Intelligent to protect when overpressure of water tank

                 I. Have pause function

                J. Fast steam out

Applications:

For 3~5 cubic meter residential and commercial steam baths

sauna steam generator Specifications:

Competitive Advantage:

Every TOLO steam generator is subjected to 6 strictly controlled tests:
    1. 48 hour continual test for circuit board
    2. Controller is tested for all functions
    3. High voltage test
    4. Earthing resistance test
    5. Power test.
    6. Operational test of every steam generator before packing
