portable Electric Bath steam generator for steam room , vapor generator

China portable Electric Bath steam generator for steam room , vapor generator supplier

Large Image :  portable Electric Bath steam generator for steam room , vapor generator

Product Details:

Place of Origin: China
Brand Name: TOLO
Certification: CE
Model Number: TOLO-E60

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: 1 set/carton
Delivery Time: 1-3 workdays
Payment Terms: T/T, Paypal, Western Union,
Supply Ability: 1800 sets
Detailed Product Description



portable Electric Bath steam generator for steam room , vapor generator





Lack of water protection function: Once the steam generator has leakage problem of the water tank, the steam generator will power off automatically.



We keep "Safety First". After serval years serving time, the steam generator parts may aging, like main circuit board , water level sensor, heating element etc. But don't worry about this, we have over-heat protect function.It will protect you far way from  dangerous.





400V 6000w TOLO Steam Bath Generator Quick Detail:



     Steam generator Type: For Wet Roma Steam bath

  • Control panel with Digital display
  • Control panel used the advanced inducing technology
  • Controls sauna temperature 35 degree to 55 degrees
  • Controls sauna time 1 minute to 60 minutes or long time
  • Intelligent to heat by segment
  • Intelligent to fill water with steam
  • Intelligent to do a self flushing cycle
  • Light can be connected to controller
  • Intelligent to indicate fault with the code
  • Can pause at working
  • To show CH can working for long
  • Intelligent to save two sets of temperature, can individual set time by memory
  • Automatically shuts down when water level is too low
  • Temperature high limit switch
  • Waterproof grade: IPX5
  • Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  • Basic Auto function: auto water inlet , auto drain, auto flushing, auto power off
  • We will provide some spare parts to our customer as replacement.





400V 6000w TOLO Stainless Steel Steam Bath Generator Description:

The improvements of TOLO steam generator differ from the other brand generator:



If one steam generator doesn't have perfect drain system, its quality is always not good enough.

TOLO steam generator use 34" full-bore.(Full-bore: full-bore straight-through type with connection between valve andpipeline or straight pipe, equal sectional area and "0" loss of flow.) It solved the water scale block the drain valve problem.



There has four valves in the steam generator industry. They are manual drain valve, old type automatical drain valve, automatical push-pull drain valve and our 3/4" full-bore auto drain valve. These 3 valves except our 3/4" full-bore auto drain valve, all of them have different problem.



1.Manual drain valve: you have to drain by yourself after each time steam bath.



2.Old type automatical drain valve: the pipe is too small. Once there has some water scale in the water tank. After some months, the drain valve will be blocked.



3.Automatical push-pull drain valve: sometimes it will not push back after it pulled, and there has leakage probelm.



4.At last, our 3/4" full-bore auto drain valve is testing for several years without any problem. Only TOLO steam generator has 3/4" full-bore auto drain valve.







Applications:



For 5~7m³ residential and commercial steam baths

A daily steam bath is a remarkable way to indulge yourself. It causes the perspiration that is the single healthiest thing you can do for your skin. Stress and negativity quickly dissipate in the soft clouds of intense yet comforting heat. A few minutes of steam daily, in the comfort of your own home, is an opportunity to improve your overall well-being in every way.





Specifications:



  1. control panel: digital and optional
  2. Power output: 6000w
  3. voltage: 110V/220V/380V/400V
  4. Current: 18.6A
  5. Main Material: stainless steel tank and shell
  6. Color: stainless steel
  7. phase: single phase/ 3 phase
  8. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  9. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  10. Shape: Cuboid
  11. Size: 405x150x280mm
  12. Room volume(cubic meter): 3~6
  13. Usage: steam sauna room
  14. working time: 1~60 minutes or long time
  15. Heating: heat elements
  16. Power source: Electric
  17. Time Setting: 1-60mins
  18. Temperature range to control: 95 F degree~131 F degree
  19. Temperature range to show on control panel: 43 F degree ~140 F degree





Parameters:



Model

Power KW

Room volume (m³)

Power requirements           50/60Hz

Current  (A)

Power        wire (Copper)          N*mm2

Dimensions  CM

Packing dimensions CM

Gross weight kg

TOLO-E30

3.0

2~4

220-240V~

13.6

3*2.5

42.5*16*30

54.5*21.5 *42

10.5~11

TOLO-E40

4.0

3~5

220-240V~

18.2

3*2.5

TOLO-E45

4.5

3.5~5.5

220-240V~

20.5

3*2.5

380-415V3N~

6.8

5*1.5

TOLO-E50

5.0

4~6

220-240V~

22.7

3*2.5

380-415V3N~

9.1

5*1.5

TOLO-E60

6.0

5~7

220-240V~

27.3

3*4.0

380-415V3N~

9.1

5*1.5

TOLO-E70

7.0

5.5~8.5

220-240V~

31.8

3*6.0

47.5*18.5*45

53.5*23*59

15.6~16.2

380-415V3N~

11.4

5*2.5

TOLO-E80

8.0

7~10

220-240V~

36.4

3*6.0

380-415V3N~

13.6

5*2.5

TOLO-E90

9.0

8~11

380-415V3N~

13.6

5*2.5

16.4~17

TOLO-E105

10.5

9~12

380-415V3N~

15.9

5*2.5

TOLO-E120

12.0

11~14

380-415V3N~

18.2

5*2.5

TOLO-E150

15.0

13~18

380-415V3N~

22.7

5*2.5

51*18.5*46

56.5*23*59

17.5~18.5

TOLO-E180

18.0

16~22

380-415V3N~

27.3

5*4.0

TOLO-E225

22.5

21~28

380-415V3N~

34.1

5*6.0

TOLO-E240

24.0

22~30

380-415V3N~

36.4

5*6.0

Notice: TOLO-E steam generator are equiped with auto drain system. 9~12 KW units could be customized to 220~240V on request.





TOLO Steam Generator Competitive Advantage:



Every TOLO-E steam generator is subjected to 6 strictly controlled tests:
    1. 48 hour continual test for circuit board
    2. Controller is tested for all functions
    3. High voltage test
    4. Earthing resistance test
    5. Power test.
    6. Operational test of every steam generator before packing
