6.0kw 380v Turkish Bath Heat Electric Sauna Steam Generator Hyperthermia Therapy
Sauna Steam Generator Quick Detail:
Description:
Quality Assurance
• ISO 9001:2008 Quality Management System ensures advanced design, perfect pre- & post-production quality and superior customer service.
• 2-year limited warranty or optional lifetime warranty offers you a worry-free lifestyle.
• Specified by leading architects, consultants, designers throughout worldwide.
• Successfully served in prestigious projects all over the world.
Installation
All compression-fitting connection.
Middle size to install easily
Steam unit and water sensor both come with easily accessible repair panel.
Motorized drain valve with the option for manual flush as needed.
Durability
• Type 304 high-quality stainless steel boiler tank & shell.
• Or galvanized enclosure with superior powder coating, corrosion-resistant, excellent clour and gloss retention.
• Industrial process high-quality 304 stainless steel heating elements with Teflon, corrosion-resistant.
• Easy Maintenance electrical probe for water level control
• Water inlet valve enhanced for 10 million operations.
• Well insulated steam boiler improves energy efficiency and safe operation.
Controls
• Water-tight control mountable in/out of steam room.
• Electronic 1~60-min. and On/Off control with indicator light.
• Electronic digital Advanced Designer series.
• Multi-memory temperature & time function offers individual settings.
• New Design stainless steel steam head .
• Fragrance of your choice.
• Chromatherapy RGB( optional).
• LED light controlled on the touch screen controller
We have more than 10 years manufacturing experience for sauna equipment.
TOLO steam generator main feature :
A. steam out right long when cold water fill in
B. Auto turn off when reaches working time.
C. Auto drain after power off
D. self flushing heating element
E. Intelligent to indicate fault with code
F. Protect when overheating
G. Auto power off when shortage of water
H. Intelligent to protect when overpressure of water tank
I. Have pause function
J. Fast steam out
Applications:
For 5~7 cubic meter residential and commercial steam baths
Competitive Advantage:
Every TOLO steam generator is subjected to 6 strictly controlled tests:
1. 48 hour continual test for circuit board
2. Controller is tested for all functions
3. High voltage test
4. Earthing resistance test
5. Power test.
6. Operational test of every steam generator before packing
sauna steam generator Specifications:
Parameters:
|
Model |
Power KW |
Room volume (m³) |
Power requirements 50/60Hz |
Current (A) |
Power wire (Copper) N*mm2 |
Dimensions CM |
Packing dimensions CM |
Gross weight kg |
|
KSA-E30 |
3.0 |
2~4 |
220-240V~ |
13.6 |
3*2.5 |
42.5*16*30 |
54.5*21.5 *42 |
10.5~11 |
|
KSA-E40 |
4.0 |
3~5 |
220-240V~ |
18.2 |
3*2.5 |
|||
|
KSA-E45 |
4.5 |
3.5~5.5 |
220-240V~ |
20.5 |
3*2.5 |
|||
|
380-415V3N~ |
6.8 |
5*1.5 |
||||||
|
KSA-E50 |
5.0 |
4~6 |
220-240V~ |
22.7 |
3*2.5 |
|||
|
380-415V3N~ |
9.1 |
5*1.5 |
||||||
|
KSA-E60 |
6.0 |
5~7 |
220-240V~ |
27.3 |
3*4.0 |
|||
|
380-415V3N~ |
9.1 |
5*1.5 |
||||||
|
KSA-E70 |
7.0 |
5.5~8.5 |
220-240V~ |
31.8 |
3*6.0 |
47.5*18.5 *45 |
53.5*23*59 |
15.6~16.2 |
|
380-415V3N~ |
11.4 |
5*2.5 |
||||||
|
KSA-E80 |
8.0 |
7~10 |
220-240V~ |
36.4 |
3*6.0 |
|||
|
380-415V3N~ |
13.6 |
5*2.5 |
||||||
|
KSA-E90 |
9.0 |
8~11 |
380-415V3N~ |
13.6 |
5*2.5 |
16.4~17 |
||
|
KSA-E105 |
10.5 |
9~12 |
380-415V3N~ |
15.9 |
5*2.5 |
|||
|
KSA-E120 |
12.0 |
11~14 |
380-415V3N~ |
18.2 |
5*2.5 |
|||
|
KSA-E150 |
15.0 |
13~18 |
380-415V3N~ |
22.7 |
5*2.5 |
51*18.5*46 |
56.5*23*59 |
17.5~18.5 |
|
KSA-E180 |
18.0 |
16~22 |
380-415V3N~ |
27.3 |
5*4.0 |
|||
|
KSA-E225 |
22.5 |
21~28 |
380-415V3N~ |
34.1 |
5*6.0 |
|||
|
KSA-E240 |
24.0 |
22~30 |
380-415V3N~ |
36.4 |
5*6.0 |
|||
|
Notice: KSA-E steam generator are equiped with auto drain system. 9~12 KW units could be customized to 220~240V on request. American power input 110V is available according to your requirement. |
||||||||
Sauna Steam Generator 6.0kw/400v For Turkish Steam-bath with Auto-drain Function
TOLO Touch Screen Control panel works video show at http://www.youtube.com/watch?v=VnbhbMf_Rq8
