Quick Detail:
Real manufacturer we are will give you strange technology support!
Description:
“Save Worry Save Trouble”!
This series is born in 2008. After years of test, it is steady performance.
You don’t need to spend a lot of time to solve the problems like a new product.
This KSA-E series steam generator is our featured products.
1) Power:150kW, voltage: 220/380V, phase:1/3
2) Two controllers: KSA-200
3) Operates machine for 1~60 minutes before turning off
4) Automatically shuts down when water level is too low
5) Controls sauna temperature
6) Temperature high limit switch
7) With cleaning and draining function
8) High quality with 2-year warranty
1. Fast steam: With the special and delicate design of the system, a large volume of steam will come out within 5 minutes after the heating elements begin to work, and quickly boosts the temperature to the setting value. The intelligent heating-by-section make heating process more efficient and minimize the energy used, more importantly, non-stop steam generation is ensured even during the water tank filling period.
2. Multi-protection. Besides the GFCI (Ground Fault Circuit Interrupter ), the KSA-E series also installed the following protection circuits: over-heat protection; lack-of-water protection; over-pressure protection, assisted by the newest microprocessor technology to give automatic diagnose message in order to give customer maximum level of safety and easy trouble-shooting when any fault happens.
3. As professional we could tell you that the decisive fact for a steam generator is actually the quality of the heating elements rather than functions. Therefore we choose the best magnesian powder, 304# stainless steel, and seal glue to guarantee a durable product. We also oxidize the heating elements surface with Teflon . More importantly, the advanced automatic washing, cooling and draining functions minimize the conglomeration of calcium and magnesium on the heating element so as to greatly extend the life of heating elements.
4. To install water magnetizing filter impurity, or pressure reducer to reduce the inlet water pressure, or external light according to customer requirements.
Applications:
Fit for home use and commercial use
Make you more healthy!
Please see the details for your installment reference:
Model |
Power KW |
Room volume (m³) |
Power requirements 50/60Hz |
Current (A) |
Power wire (Copper) N*mm2 |
Dimensions CM |
Packing dimensions CM |
Gross weight kg |
KSA-E150 |
15.0 |
13~18 |
380-415V3N~ |
22.7 |
5*2.5 |
51*18.5*46 |
56.5*23*59 |
17.5~18.5 |
KSA-E150
Main feature :
A. steam out right long when cold water fill in
B. Auto turn off when reaches working time.
C. Auto drain after power off
D. self flushing heating element
E. Intelligent to indicate fault with code
F. Protect when overheating
G. Auto power off when shortage of water
H. intelligent to protect when overpressure of water tank
I. Have pause function
Competitive Advantage:
All our product are subjected to 6 strictly controlled tests:
The quality you felt relieved.
1. Operational test of every steam generator before packing
2. Power test.
3. Earthing resistance test
4. High voltage test
5. Controller is tested for all functions
6. 48 hour continual test for circuit board
