Stainless Steel Sauna Steam Generator , Wired Touch Screen Control Panel
Sauna Steam Generator Quick Detail:
Description:
We have more than 10 years manufacturing experience for sauna equipment.
TOLO steam generator main feature :
A. Big water flow in drain valve (our original design)
B.steam out right long when cold water fill in
C. Auto drain after power off
D. self flushing heating element
E. Intelligent to indicate fault with code
F. Protect when overheating
G. Auto power off when shortage of water
H. Intelligent to protect when overpressure of water tank
I. Have pause function
J. Fast steam out
K.Auto turn off when reaches working time.
Applications:
For 3.5~5.5 cubic meter residential and commercial steam baths
sauna steam generator Specifications:
Parameters:
|
Model |
Power KW |
Room volume (m³) |
Power requirements 50/60Hz |
Current (A) |
Power wire (Copper) N*mm2 |
Dimensions CM |
Packing dimensions CM |
Gross weight kg |
|
TOLO-E30 |
3.0 |
2~4 |
220-240V~ |
13.6 |
3*2.5 |
42.5*16*30 |
54.5*21.5*42 |
10.5~ 11 |
|
TOLO-E40 |
4.0 |
3~5 |
220-240V~ |
18.2 |
3*2.5 |
|||
|
TOLO-E45 |
4.5 |
3.5~5.5 |
220-240V~ |
20.5 |
3*2.5 |
|||
|
380-415V3N~ |
6.8 |
5*1.5 |
||||||
|
TOLO-E50 |
5.0 |
4~6 |
220-240V~ |
22.7 |
3*2.5 |
|||
|
380-415V3N~ |
9.1 |
5*1.5 |
||||||
|
TOLO-E60 |
6.0 |
5~7 |
220-240V~ |
27.3 |
3*4.0 |
|||
|
380-415V3N~ |
9.1 |
5*1.5 |
||||||
|
TOLO-E70 |
7.0 |
5.5~8.5 |
220-240V~ |
31.8 |
3*6.0 |
47.5*18.5*45 |
53.5*23*59 |
15.6~ 16.2 |
|
380-415V3N~ |
11.4 |
5*2.5 |
||||||
|
TOLO-E80 |
8.0 |
7~10 |
220-240V~ |
36.4 |
3*6.0 |
|||
|
380-415V3N~ |
13.6 |
5*2.5 |
||||||
|
TOLO-E90 |
9.0 |
8~11 |
380-415V3N~ |
13.6 |
5*2.5 |
16.4~ 17 |
||
|
TOLO-E105 |
10.5 |
9~12 |
380-415V3N~ |
15.9 |
5*2.5 |
|||
|
TOLO-E120 |
12.0 |
11~14 |
380-415V3N~ |
18.2 |
5*2.5 |
|||
|
TOLO-E150 |
15.0 |
13~18 |
380-415V3N~ |
22.7 |
5*2.5 |
51*18.5*46 |
56.5*23*59 |
17.5~ 18.5 |
|
TOLO-E180 |
18.0 |
16~22 |
380-415V3N~ |
27.3 |
5*4.0 |
|||
|
TOLO-E225 |
22.5 |
21~28 |
380-415V3N~ |
34.1 |
5*6.0 |
|||
|
TOLO-E240 |
24.0 |
22~30 |
380-415V3N~ |
36.4 |
5*6.0 |
|||
|
Notice: TOLO-E steam generator are all equiped with auto drain system. 9~12 KW units could be customized to 220~240V on request. We also produce 110V steam geneartor according to your requirement. |
||||||||
Competitive Advantage:
Every TOLO steam generator is subjected to 6 strictly controlled tests:
1. 48 hour continual test for circuit board
2. Controller is tested for all functions
3. High voltage test
4. Earthing resistance test
5. Power test.
6. Operational test of every steam generator before packing
