Touch Screen Steam Bath Generators , High Efficient Steam Home Bath Generators

China Touch Screen Steam Bath Generators , High Efficient Steam Home Bath Generators supplier

Large Image :  Touch Screen Steam Bath Generators , High Efficient Steam Home Bath Generators

Product Details:

Place of Origin: China
Brand Name: TOLO
Certification: CE
Model Number: TOLO-E60

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: 1 set/carton
Delivery Time: 1-3 workdays
Payment Terms: T/T, Paypal, Western Union,
Supply Ability: 1800 sets
Detailed Product Description
Material: 304# Stainless Steel Water Tank Auto Water Inlet: Yes
Auto Power Off: Yes Auto Drain: Yes
Auto Flushing: Yes

Touch Screen Steam Bath Generators , High Efficient Steam Home Bath Generators







Steam Bath Generator Quick Detail:





TOLO Turkish Steam-bath Features: Fast Steam!

The steam generator make the steam come out in 2 minutes.



  1. control way: wired waterproof touch screen control panel
  2. Power source: Electric
  3. Power output: 6.0kw(6000w)
  4. Voltage: 110V/220V/380~415V
  5. phase: 1/3
  6. Current: 27.3A/9.1A
  7. Time Setting: 1-60mins
  8. Temperature range to control: 95 F degree~131 F degree
  9. Temperature range to show on control panel: 43 F degree ~140 F degree
  10. Main Material: stainless steel tank and galvanizing and powder coated shellshell
  11. Color: grey green
  12. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  13. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  14. Shape: Cuboid
  15. Room volume(cubic meter): 5~7
  16. Usage: steam bath room
  17. working time: 1~60 minutes or long time
  18. Heating: heat elements





Description:



We have more than 10 years manufacturing experience for sauna equipment.



TOLO steam generator main feature :

                  A. steam out right long when cold water fill in

                  B. Auto turn off when reaches working time.

                  C. Auto drain after power off

                  D. self flushing heating element

                  E. Intelligent to indicate fault with code

                  F. Protect when overheating

                  G. Auto power off when shortage of water

                  H. Intelligent to protect when overpressure of water tank

                  I. Have pause function

                 J. Fast steam out



Mirror-polished Stainless Steel body to prevent rust and looks luxurious.

  • The steam generator is intelligent to heat by segment and can save sets of temperature and individual set time by memory
  • the water in the steam generator boiler is held at around 80 degrees until the steam on demand button located inside the steam room is pushed by the customers - then steam will be delivered by the generator within a few seconds, saving energy and costs during quieter periods of operation.
  • Intelligent to indicate fault with the code.
  • To show CH can work for long and pause, fill water with steam, automatic to turn off, a self flushing cycle ,with pressure to drain.
  • Heating by segment: there has 3 groups of heating elements inside the water tank to provide sequential heating (from cold all 3 groups operate for maximum power and rapid heating, when the steam room temperature is almost reached, then group 1 stop, when the required temperature is achieved, then group 2 stop. The group 3 alternates on and off to gently maintain the temperature without large fluctuations. KSA-E steam generators feature an advanced electronic control with on board diagnostics having a series of LEDs lights to show each operation of the generator. The controller has 6 bottoms to set working stages. working time 1-60mins can be adjusted or long ,the setting temperature of the steam will be in 6-60C degrees and can be adjusted between 35-55C degree (95-131F degree).
  • At last, the drain valve start and the fresh water inlet valve open to give a period of continuous washing and draining. Washing and draining the generator reduces water scale, cooling the elements for their useful life be longer.



Applications:



For 5~7 cubic meter residential and commercial steam baths



Competitive Advantage:



Every TOLO steam generator is subjected to 6 strictly controlled tests:
    1. 48 hour continual test for circuit board
    2. Controller is tested for all functions
    3. High voltage test
    4. Earthing resistance test
    5. Power test.
    6. Operational test of every steam generator before packing



sauna steam generator Specifications:



Parameters:

Model

Power KW

Room volume (m³)

Power requirements           50/60Hz

Current (A)

Power        wire (Copper)          N*mm2

Dimensions  CM

Packing dimensions CM

Gross weight kg

KSA-E30

3.0

2~4

220-240V~

13.6

3*2.5

42.5*16*30

54.5*21.5 *42

10.5~11

KSA-E40

4.0

3~5

220-240V~

18.2

3*2.5

KSA-E45

4.5

3.5~5.5

220-240V~

20.5

3*2.5

380-415V3N~

6.8

5*1.5

KSA-E50

5.0

4~6

220-240V~

22.7

3*2.5

380-415V3N~

9.1

5*1.5

KSA-E60

6.0

5~7

220-240V~

27.3

3*4.0

380-415V3N~

9.1

5*1.5

KSA-E70

7.0

5.5~8.5

220-240V~

31.8

3*6.0

47.5*18.5 *45

53.5*23*59

15.6~16.2

380-415V3N~

11.4

5*2.5

KSA-E80

8.0

7~10

220-240V~

36.4

3*6.0

380-415V3N~

13.6

5*2.5

KSA-E90

9.0

8~11

380-415V3N~

13.6

5*2.5

16.4~17

KSA-E105

10.5

9~12

380-415V3N~

15.9

5*2.5

KSA-E120

12.0

11~14

380-415V3N~

18.2

5*2.5

KSA-E150

15.0

13~18

380-415V3N~

22.7

5*2.5

51*18.5*46

56.5*23*59

17.5~18.5

KSA-E180

18.0

16~22

380-415V3N~

27.3

5*4.0

KSA-E225

22.5

21~28

380-415V3N~

34.1

5*6.0

KSA-E240

24.0

22~30

380-415V3N~

36.4

5*6.0

Notice: KSA-E steam generator are equiped with auto drain system. 9~12 KW units could be customized to 220~240V on request. American power input 110V is available according to your requirement.





The benefit of the steam bath:



Circulation

During a steam bath, blood vessels enlarge in response to heat.

This action translates into an increased flow of blood throughout the body.

More blood means more oxygen and nutrients delivered to the cells,

which accelerates the repair of tissue damaged through exercise

Hyperthermia

Hyperthermia is defined by Merriam-Webster's online dictionary as an "exceptionally high fever,

especially induced artificially for therapeutic purposes."

Many invasive organisms cannot survive once the body exceeds its normal temperature.

Dr. Zane Gard, board-certified applied kinesiologist,

said that "The only detoxification program that has proven

successful in removing fat stored toxins from the body

is hyperthermia, or heat stress detoxification."

Steam therapy reinvigorates the skin, offering a natural alternative to chemical treatments.

Dr. Reinhard R. Bergel, in a special report extolling the restorative benefits of steam,

said: “A great advantage of the steam bath lies in its highly beneficial effect on the skin,

a feature particularly appreciated by women.

The moist heat stimulates the subcutaneous blood flow and cleanses the skin intensively,

opening the pores, removing dead skin and impurities and leaving the skin feeling soft,

clean, and silky smooth.”

By opening the pores through perspiration,

steam induces the expulsion of toxins, rectifying exercise-related skin problems.





Stainless Steel Sauna Steam Generator 6.0kw/400v For Turkish Steam-bath with Auto-drain Function



TOLO Touch Screen Control panel works video show at http://www.youtube.com/watch?v=VnbhbMf_Rq8
